drylin® T profile guides provide compact, adjustable carriages on hard‑anodized rails. This catalog details preload adjustment, carriage types and interchangeability to replace recirculating ball guides in applications where noise and corrosion are concerns.
Dimensional tables are paired with permissible moments and running clearances. Recommendations cover rail mounting on aluminum frames, thermal expansion gaps and reference edge usage.
Accessories—end caps, scrapers and manual adjusters—are listed with part numbers for rapid configuration.
Examples show quiet pick‑and‑place axes and camera stages where dry operation eliminates grease management.
Download: igus – drylin T Linear Guide Systems
